Ongrid Inverter Three Phase
Ongrid Inverter Three Phase
Ongrid Inverter Three Phase
Ongrid Inverter Three Phase
On-Grid Inverter

40 kW Sunora On-Grid inverter 3ph

Original price was: ₹126,583.33.Current price is: ₹113,925.00.(Inclusive of all taxes)

Quantity:

Warranty Assurance

Genuine Products

Direct Delivery

Certified Excellence

Warranty Information
10 Years Unconditional warranty
Share:
Standards & Certifications
View More

Description

The 40 kW Sunora 3 Phase On-Grid Solar Inverter is a high-performance solution designed for large-scale commercial and industrial solar installations. This 40 kW 3 Phase on grid solar inverter delivers efficient power conversion and ensures seamless grid synchronization for consistent output. With advanced MPPT technology, it maximizes solar energy generation even in fluctuating sunlight conditions.

This 3 Phase solar inverter features intelligent monitoring systems that provide real-time insights into performance, helping users manage energy effectively. The Three Phase design allows balanced load distribution and stable power supply, making it suitable for heavy-duty applications.

Constructed with durable materials and equipped with advanced safety features, this 40 kW 3 Phase on grid solar inverter ensures safe and long-lasting operation. Its easy installation, low maintenance, and high efficiency make it an excellent choice for reducing electricity costs and improving overall system performance.

Download Product Datasheet

Additional information

Max. Input Power

60kW (Supports up to 150% PV array oversizing)
Max. DC Voltage

1100V
Start-up Voltage

180V
Nominal Voltage

600V
MPPT Voltage Range

200V – 1000V
Number of MPP Trackers

4
Strings per MPP Tracker

2
Max. Input Current per MPPT

32A
Max. Short-circuit Current per MPPT

40A
Nominal Output Power

40kW
Max. AC Apparent Power

45kVA
Nominal AC Voltage

230/400V (3L/N/PE or 3L/PE range)
Max. Output Current

66.7A
Frequency

50/60Hz (Range: 45–55Hz)
Dimensions

590 x 480 x 237 mm
Weight

39kg
Protection Rating

IP66 (Dust-tight and protected against powerful water jets)
Cooling

Intelligent Air Cooling
Operating Temperature

-25°C to +60°C
Max Efficiency

98.4%
Surge Protection

Type II for both DC and AC
Grid Protection

Anti-islanding and Grid Monitoring
High Power Input

Supports 150% PV oversizing and 16A per string to handle large, modern bifacial modules
Advanced Efficiency

Uses SiC power components and a low 180V start-up to maximize energy generation time
Smart Safety

Includes AFCI protection to prevent electrical fires and integrated Anti-PID function to protect panel health
Safety Features

DC Reverse Polarity, AC Short-circuit, Insulation Resistance Monitoring, and Residual-current Monitoring (GFCI)
Communication

RS485, supports WiFi and 4G; remote firmware updates supported
