Sale!

10 kW Sunora Hybrid Inverter 3ph

(1 customer review)

Original price was: ₹163,333.33.Current price is: ₹147,000.00.(Inclusive of all taxes)

Quantity:

Warranty Assurance

Genuine Products

Direct Delivery

Certified Excellence

Warranty Information
10 Years Unconditional warranty
Share:

Description

The 10 kW Sunora Hybrid Inverter 3 Phase is a powerful and intelligent energy solution designed for residential, commercial, and industrial solar applications. This 10 kW 3 Phase hybrid solar inverter efficiently manages power from solar panels, batteries, and the utility grid to ensure uninterrupted electricity supply and maximum energy savings. Equipped with advanced MPPT technology, it continuously optimizes solar energy generation by adapting to changing sunlight conditions throughout the day.

This 3 Phase hybrid inverter supports real-time monitoring of voltage, battery status, power consumption, and system performance, allowing users to manage energy usage efficiently. The Three Phase design ensures balanced load distribution and stable operation, making it ideal for properties with higher power requirements. Its hybrid functionality allows seamless switching between solar, battery backup, and grid power for enhanced reliability during power outages.

Built with advanced safety protections including overload, short circuit, overvoltage, and temperature control, this 10 kW 3 Phase hybrid solar inverter ensures safe and long-lasting performance. Its durable construction, smart energy management system, and low maintenance requirements make it a cost-effective solution for reducing electricity bills and improving energy independence. Ideal for users looking for a reliable and high-efficiency hybrid solar inverter for long-term sustainable energy solutions.

Download Product Datasheet

Additional information

Max. Input Voltage

1,000 V

Start-up Voltage

135 V

Rated Input Voltage

600 V

MPPT Input Voltage Range

135–900 V

No. of MPPT / Strings per MPPT

2 / (1/2)

Max. MPPT Input Current

16 A / 32 A

MPPT Short-circuit Current

20 A / 40 A

Max. Input Apparent Power

20,000 VA

Rated AC Voltage

3L/N/PE, 220/380 V, 230/400 V, 240/415 V

Rated Output Current

14.5 A

Max. Input/Output Current

30.3 / 19.7 A

Rated Output Power

10,000 W

Max. Output Apparent Power

10,000 VA

On-grid/Off-grid Switching Time

< 10 ms

Battery Voltage Range

135–800 V

Max. Charge/Discharge Power

12,500 W / 11,000 W

Max. Charge/Discharge Current

25 A / 25 A

Compatible Battery Types

Li-ion and Lead-acid

Max. Efficiency

97.6%

MPPT Efficiency

99.9%

Integrated Protection

Anti-islanding, DC Reverse Polarity, DC Circuit Breaker, Insulation Resistor Detection

Surge Protection

DC Type II / AC Type II

Dimensions (W x H x D)

510 x 442 x 222 mm

Weight

24 kg

Operating Temperature

-30°C to 60°C

Protection Rating

IP65

Cooling

Smart Cooling

Warranty

10 Years

Smart Management

Programmable supply priority for PV, Battery, or Grid

Generator Support

Supports diesel generators to charge the battery directly

Monitoring

Smartphone-enabled commissioning via WiFi/App with an LCD touchscreen color panel

Protection

Anti-islanding, DC Reverse Polarity, DC Circuit Breaker, Insulation Resistor Detection, and Surge Protection (Type II DC/AC)
