4 kW Sunora Hybrid Inverter 1ph

Description

Sunora Solar 4kW Single Phase Hybrid Inverter
Download Product Datasheet

Recommended Max. PV Input Power	6500 Wp
Max. Input Voltage	500 V
Start-up Voltage	125 V
MPPT Input Voltage Range	150–430 V
MPPT Short-circuit Current	20 A
No. of MPPT / Strings per MPPT	2 / 1
Rated Output Power	5000 W
Max. Output Apparent Power	5500 VA
Max. Input Apparent Power	7590 VA
Rated Output Current	21.7 A
Max. Input/Output Current	33 / 23.9 A
Operating Range	180–300 V
Frequency	50/60 Hz (Range: $45–55$ Hz)
Max. Output Current	23.9 A
On-grid/Off-grid Switching Time	<10 ms
Battery Type	Compatible with Li-ion and Lead-acid
Rated Voltage	48 V
Battery Voltage Range	40–60 V
Max. Charge/Discharge Power	5000 W
Max. Charge/Discharge Current	120 A
Communication Port	CAN / RS485
Max. Efficiency	97.6%
Euro Efficiency	96.5%
MPPT Efficiency	99.9%
Surge Protection	DC Type II / AC Type II
Dimensions (WxHxD)	580 x 330 x 232 mm
Weight	21 kg
Protection Rating	IP66
Cooling	Smart Cooling
Operating Temp	-25°C to 60°C
Warranty	10 Years
Smart Management	Programmable supply priority (PV, Battery, or Grid) and remote firmware updates
Generator Support	Can support a diesel generator to charge the battery directly
Monitoring	Free online monitoring and smartphone-enabled commissioning
