12 kW Sunora Hybrid Inverter 3ph

Description

Sunora Solar 12kW Three Phase Hybrid Inverter
Download Product Datasheet

Recommended Max. PV Input Power	18,000 Wp
Maximum Input Voltage	1,000 V
Start-up Voltage	135 V
Rated Input Voltage	600 V
MPPT Voltage Range	135–900 V
Number of MPPT / Strings per MPPT	2 MPPTs / 1 string per MPPT
Max. Input Current per MPPT	16A / 32A
Short-circuit Current per MPPT	20A / 40A
Rated Output Power	12,000 W
Max. Output Apparent Power	13,200 VA
Rated AC Voltage	3L/N/PE (220/380V, 230/400V, 240/415V)
Rated Output Current	17.4 A
Max. Output Current	19.7 A
Grid Connection Mode	Three-phase (3L/N/PE)
On-grid/Off-grid Switching Time	< 10 ms
Battery Type	Compatible with Li-ion and Lead-acid
Battery Voltage Range	135–800 V
Max. Charge/Discharge Power	12,500 W / 13,200 W
Max. Charge/Discharge Current	25 A / 25 A
Communication Port	CAN / RS485
Max. Efficiency	97.6%
MPPT Efficiency	99.9%
Integrated Protection	Anti-Islanding, DC Reverse Polarity, DC Circuit Breaker, Insulation Resistor Detection
Surge Protection	DC Type II / AC Type II
Dimensions (W x D x H)	510 x 442 x 222 mm
Weight	24 kg
Operating Temperature	-30°C to 60°C
Protection Rating	IP65
Cooling	Smart Cooling
Warranty	10 Years
Smart Management	Programmable supply priority for PV, Battery, or Grid
Generator Support	Supports diesel generators to charge the battery directly
Monitoring	Smartphone-enabled commissioning via WiFi/App with an LCD touchscreen color panel
Protection	Anti-islanding, DC Reverse Polarity, DC Circuit Breaker, Insulation Resistor Detection, and Surge Protection (Type II DC/AC)
